Tobacco Packaging Machine
Tobacco Packaging Machine
The Tobacco Packaging Machine is an advanced automated system designed for the efficient and precise packaging of various tobacco products. Suitable for products such as cigarettes, cigars, and loose tobacco, this machine ensures that the packaging process preserves product quality while maximizing production efficiency. Its robust design and advanced technology make it ideal for high-volume manufacturing environments.
Technical Data
| Model | SK-300BF | SK-600BF | SK-900BF |
| Packing speed | 20-40 cuts per minute/per column |
20-40 cuts per minute/per column |
20-40 cuts per minute/per column |
| Columns | 2-4 Columns | 3-10 Columns | 4-16 Columns |
| Bag Size | L:50-180mm W:20-70mm | L:50-180mm W:20-95mm | L:50-180mm W:20-105mm |
| Film Width Film Thickness |
Max:300mm; 0.07-0.1mm |
Max:600mm; 0.07-0.1mm |
Max:900mm; 0.07-0.1mm |
| Bag Seal type | Back Seal, Three Side Seal, Four Side Seal | Back Seal, Three Side Seal, Four Side Seal | Back Seal, Three Side Seal, Four Side Seal |
| Cut type |
1.Flat cut 2.Serrated cut 3.Round corner cut 4.Shaped cut |
1.Flat cut 2.Serrated cut 3.Round corner cut 4.Shaped cut |
1.Flat cut 2.Serrated cut 3.Round corner cut 4.Shaped cut |
| Power | 3.5KW | 5.5KW | 7.5KW |
| Power supply | AC220V 1phase 50Hz/ AC380V 3phases 50Hz | AC220V 1phase 50Hz/ AC380V 3phases 50Hz | AC220V 1phase 50Hz/ AC380V 3phases 50Hz |
| Air consumption | 0.8m³/min 0.8Mpa | 0.8m³/min 0.8Mpa | 0.8m³/min 0.8Mpa |
| Dimension | 1385*918*2005 mm | 1685*1300*2005mm | 1700*1600*2500mm |
| Weights | 400kg | 600kg | 950kg |
Application Range
- Packaged cigarettes
- Loose tobacco
- Cigar and cigarillo packaging
- Filter tips
- Rolling tobacco
NOTE: The information listed in the chart is strictly indicative and will depend on the specific features of each machine.
