Liquid Filling Machine
Liquid Filling Machine
The Liquid Filling Machine is a highly efficient and versatile system designed for the precise filling of various liquid products into containers of different sizes. Ideal for industries such as food and beverage, pharmaceuticals, cosmetics, and chemicals, this machine integrates advanced filling technology to ensure accuracy, speed, and consistency in the production process.
Technical Data
| Model | SK-GZL-6L | SK-GZL-8L | SK-GZL-10L | SK-GZL-12L |
| Filling range | 50 ~ 1000ml | 50 ~ 1000ml | 50 ~ 1000ml | 50 ~ 1000ml |
|
Filling speed |
< 30bottles/min ( ba |
< 40bottles/min ( ba |
＜50bottles/min (ba |
<60bottles/min ( ba |
|
Measurement accuracy |
± 1% | ± 1% | ± 1% | ± 1% |
| Power | 1.75kw. 220v | 2.1kw. 220v | 2.5kw, 220v | 2.8kw. 220V |
|
Working air pressure |
6- 7kg/cm² | 66- 7kg/cm² | 66- 7kg/cm² | 6- 7kg/cm² |
|
Gas consumption |
05-0.7m³/min | 05-0.8m³/min | 0.6-0.9m³/min | 0.8-1m³/min |
|
Weight |
450kg | 500kg | 550kg | 600kg |
Application Range
- Food and beverages (juices, sauces, oils)
- Pharmaceuticals (syrups, medications)
- Cosmetics (lotions, creams)
- Chemicals (cleaners, detergents)
- Industrial fluids (lubricants, adhesives)
NOTE: The information listed in the chart is strictly indicative and will depend on the specific features of each machine.
