Bottle Liquid Filling Machine
Bottle Liquid Filling Machine
The Bottle Liquid Filling Machine is a state-of-the-art system designed to accurately and efficiently fill liquid products into various types of bottles. Ideal for industries including food and beverage, pharmaceuticals, cosmetics, and chemicals, this machine ensures precision and speed in the filling process, enhancing overall production efficiency.
Technical Data
| Model | SK-GZL-6L | SK-GZL-8L | SK-GZL-10L | SK-GZL-12L |
| Filling range | 50 ~ 1000ml | 50 ~ 1000ml | 50 ~ 1000ml | 50 ~ 1000ml |
|
Filling speed |
< 30bottles/min ( Base on100 ~ 500ml ) | < 40bottles/min ( Base on100 ~ 500ml ) | ＜50bottles/min (Base on100 ~ 500ml ) | <60bottles/min ( Base on100 ~ 500ml ) |
|
Measurement accuracy |
± 1% | ± 1% | ± 1% | ± 1% |
| Power | 1.75kw. 220v | 2.1kw. 220v | 2.5kw, 220v | 2.8kw. 220V |
|
Working air pressure |
6- 7kg/cm² | 66- 7kg/cm² | 66- 7kg/cm² | 6- 7kg/cm² |
|
Gas consumption |
05-0.7m³/min | 05-0.8m³/min | 0.6-0.9m³/min | 0.8-1m³/min |
|
Weight |
450kg | 500kg | 550kg | 600kg |
Application Range
- Food and beverages (juices, sauces, oils)
- Pharmaceuticals (syrups, medications)
- Cosmetics (lotions, serums)
- Chemicals (cleaners, detergents)
- Industrial liquids (lubricants, adhesives)
NOTE: The information listed in the chart is strictly indicative and will depend on the specific features of each machine.
