Filling Line
Filling Line
The Filling Line is a comprehensive automated system designed for the efficient and precise filling of liquids, pastes, and other fluid products into a variety of containers. This versatile line integrates filling, capping, and labeling functions, ensuring a smooth and high-speed production process. It is suitable for a wide range of industries, including food and beverage, pharmaceuticals, cosmetics, and chemicals.
Technical Data
| Model | SK-GZL-6L | SK-GZL-8L | SK-GZL-10L | SK-GZL-12L |
| Filling range | 50 ~ 1000ml | 50 ~ 1000ml | 50 ~ 1000ml | 50 ~ 1000ml |
Filling speed | < 30bottles/min ( Base on100 ~ 500ml ) | < 40bottles/min ( Base on100 ~ 500ml ) | ＜50bottles/min (Base on100 ~ 500ml ) | <60bottles/min ( Base on100 ~ 500ml ) |
Measurement accuracy | ± 1% | ± 1% | ± 1% | ± 1% |
| Power | 1.75kw. 220v | 2.1kw. 220v | 2.5kw, 220v | 2.8kw. 220V |
Working air pressure | 6- 7kg/cm² | 66- 7kg/cm² | 66- 7kg/cm² | 6- 7kg/cm² |
Gas consumption | 05-0.7m³/min | 05-0.8m³/min | 0.6-0.9m³/min | 0.8-1m³/min |
Weight | 450kg | 500kg | 550kg | 600kg |
Application Range
- Food and beverages (sauces, juices, oils)
- Pharmaceuticals (syrups, ointments)
- Cosmetics (creams, lotions)
- Chemicals (cleaners, detergents)
- Industrial fluids (lubricants, adhesives)
NOTE: The information listed in the chart is strictly indicative and will depend on the specific features of each machine.
