16 Heads Liquid Filling Line
16 Heads Liquid Filling Line
The 16 Heads Liquid Filling Line is a high-efficiency automated system designed for the precise and rapid filling of liquid products into containers. Featuring sixteen filling heads, this line is ideal for high-volume production environments, ensuring consistent and accurate filling for a wide range of liquid products. It integrates filling, capping, and labeling processes, providing a comprehensive solution for liquid packaging needs.
Technical Data
| Model | SK-GZL-6L | SK-GZL-8L | SK-GZL-10L | SK-GZL-12L |
| Filling range | 50 ~ 1000ml | 50 ~ 1000ml | 50 ~ 1000ml | 50 ~ 1000ml |
|
Filling speed |
< 30bottles/min ( Base on100 ~ 500ml ) | < 40bottles/min ( Base on100 ~ 500ml ) | ＜50bottles/min (Base on100 ~ 500ml ) | <60bottles/min ( Base on100 ~ 500ml ) |
|
Measurement accuracy |
± 1% | ± 1% | ± 1% | ± 1% |
| Power | 1.75kw. 220v | 2.1kw. 220v | 2.5kw, 220v | 2.8kw. 220V |
|
Working air pressure |
6- 7kg/cm² | 66- 7kg/cm² | 66- 7kg/cm² | 6- 7kg/cm² |
|
Gas consumption |
05-0.7m³/min | 05-0.8m³/min | 0.6-0.9m³/min | 0.8-1m³/min |
|
Weight |
450kg | 500kg | 550kg | 600kg |
Application Range
- Food and beverages (juices, sauces, oils)
- Pharmaceuticals (syrups, medications)
- Cosmetics (lotions, creams)
- Chemicals (cleaners, detergents)
- Industrial liquids (lubricants, adhesives)
NOTE: The information listed in the chart is strictly indicative and will depend on the specific features of each machine.
